HH52

Design

Designer

HH Catamarans & Morrelli Melvin

Naval architect

Morrelli & Melvin

Interior designer

HH Catamarans

Summary

Best Suited For

• Bluewater Cruising

  From the published figures: CE Category A · LOA 17.05 m

• Performance Cruising

  From the published figures: performance cruiser · 3 cabins

• Liveaboard

  From the published figures: LOA 17.05 m · 3 cabins

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Speed & Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

55.9 ft (17.05 m)

Hull length

51.8 ft (15.8 m)

LWL

49.6 ft (15.11 m)

Beam

24.4 ft (7.44 m)

Draft (min)

5.4 ft (1.65 m)

Draft (max)

11.6 ft (3.54 m)

Air draft

79.7 ft (24.29 m)

Displacement

28,660 lb (13,000 kg)

Ballast

—

Cabins

2–3

Heads

—

Berths

—

Sail Plan

Main sail

958 ft² (89 m²)

Jib

355 ft² (33 m²)

Genoa

657 ft² (61 m²)

Sail area

—

Downwind sail area

1,733 ft² (161 m²)

Rig type

—

Engine and Tanks

Engine

38 hp (Beta)

Engine count

2

Engine manufacturer

Beta

Propulsion type

—

Fuel capacity

—

Fresh water capacity

—

Black water capacity

—

Construction

Mast material

—

Hull material

—

Deck material

—

Keel type

—

Rudder type

—

Steering wheels

—

Builder's Own Figures

Performance Analysis

Morrelli Melvin

Fractional Reacher

108 m2

Storm Jib

15 m2

Batteries

LiFePO4, 304Ah @48v

Mast head Gennaker

161 m2

Cruising Range at 7 knots

540 nm

Classification

CE Category A, Module B

Solar Power

4250 watts (approx., not on OC models)

Overlapping Solent

61 m2

Hull Beam

1.64 m

Self-tacking Staysail

33 m2

Fractional top down Furling Gennaker

136.87 m2

CE Max Load Displacement

17500 kg

Mast Tube Length

21 m

Configuration

SC 'Sports Cruising Aft Helm'

Films of this model from the builder's official YouTube channel (HH Catamarans). They are the builder's own; the figures above are the reference.

•

  HH52 TABOO II Walkthrough and Sailing

  HH Catamarans · 7/14/2026

•

  Owner Testimonial: HH52 About Time

  HH Catamarans · 4/21/2026

•

  HH52 Sets Sail in Annapolis

  HH Catamarans · 2/4/2026

•

  HH52 Sets Sail

  HH Catamarans · 2/20/2025

Videos whose title names the HH52, from the channel the builder's site links; last checked 9/30/2026. Playing one loads YouTube's player, which may set cookies.

About HH Catamarans

Semi-custom

Performance cruising catamaran brand of the Hudson Yacht Group, formed in 2012 and built at its own yards in Xiamen, China and Cebu, Philippines.

The HH Catamarans Range

Every model HH Catamarans publishes, by length — where this one sits in the range.

1. HH8888 ft
2. HH6665.9 ft
3. HH52· this model55.9 ft
4. HH4450.2 ft
5. HH4649 ft
