HH50

Name: HH50
Brand: HH Catamarans

Discontinued

1 / 10

HH50-5 — HH Catamarans

Design

Designer: Morrelli & Melvin
Naval architect: Morrelli & Melvin

Summary

Sailing CatamaranSailCE A

Length overall: 51.8 ft
Beam: 24.4 ft
Draft: 5.1 ft
Air draft: 76.5 ft
Displacement: 29,072 lb
Cabins: 3–4

* A standard reference image, not the actual boat — shown to help visualise this model's published dimensions.

Best Suited For

Bluewater Cruising
From the published figures: CE Category A · LOA 15.79 m
Performance Cruising
From the published figures: performance cruiser · 4 cabins
Liveaboard
From the published figures: LOA 15.79 m · 4 cabins

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Sail area / displacement

How much sail the boat carries for its weight — its power in light air.

25.1· Racing

How it is worked out

sail area (ft²) ÷ (displacement as ft³ of seawater)^⅔

mainsail + genoa, added up

Displacement / length

How heavy the boat is for its waterline length. Lower is lighter and quicker; higher is steadier and roomier.

111· Light

How it is worked out

displacement (long tons) ÷ (0.01 × waterline length in ft)³

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Speed & Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Speed

Cruising speed8.5 kn
Top speednot published

Design Category

Certified CE design category A (Ocean): the wind and waves the EU Recreational Craft Directive says this boat is designed to take.

D
Sheltered waters
Wind
up to Beaufort 4
Waves
up to 0.3 m
C
Inshore
Wind
up to Beaufort 6
Waves
up to 2 m
B
Offshore
Wind
up to Beaufort 8
Waves
up to 4 m
AThis boat
Ocean
Wind
above Beaufort 8
Waves
above 4 m

Design limits set by the EU Recreational Craft Directive (2013/53/EU), in significant wave height. A category covers the conditions of those below it. It is the limit the boat was designed to, not a promise that it is safe in any conditions within it — that judgement stays with the skipper.

Dimensions

LOA: 51.8 ft (15.79 m)
Hull length: —
LWL: 48.9 ft (14.89 m)
Beam: 24.4 ft (7.44 m)
Draft (min): 5.1 ft (1.56 m)
Draft (max): —
Air draft: 76.5 ft (23.33 m)
Displacement: 29,072 lb (13,187 kg)
Ballast: —
Cabins: 3–4
Heads: —
Berths: —

Sail Plan

Main sail: 873 ft² (81.13 m²)
Jib: 479 ft² (44.5 m²)
Genoa: 611 ft² (56.8 m²)
Sail area: —
Downwind sail area: 1,459 ft² (135.5 m²)
Rig type: —

Engine and Tanks

Engine: 38 hp (Beta)
Engine count: 2
Engine manufacturer: Beta
Propulsion type: —
Fuel capacity: —
Fresh water capacity: —
Black water capacity: —

Construction

Mast material: —
Hull material: —
Deck material: —
Keel type: —
Rudder type: —
Steering wheels: —

Builder's Own Figures

Version: Ocean Cruising (fixed keels); Sport Cruising: air draft 24.29 m, draft 1.65-3.3 m (daggerboards), light ship 11,573 kg, main 83.08 m2
Classification: CE Category A, Module B
Displacement Max Load: 17,000 kg
Propulsion: 2x Beta 38hp, optional EcoDrive Hybrid
Bridge Deck Clearance: 900 mm
Fractional Reacher: 101.8 m2
Storm Jib: 9.0 m2

Figures read fromhhcatamarans.com/hh50· Principal Particularsread 9/13/2026
