HH66

Design

Designer

Morrelli & Melvin

Naval architect

Morrelli & Melvin

Summary

Best Suited For

• Bluewater Cruising

  From the published figures: CE Category A · LOA 20.1 m

• Performance Cruising

  From the published figures: performance cruiser · 4 cabins

• Liveaboard

  From the published figures: LOA 20.1 m · 4 cabins

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Speed & Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

65.9 ft (20.1 m)

Hull length

—

LWL

65 ft (19.8 m)

Beam

28.5 ft (8.7 m)

Draft (min)

6.4 ft (1.96 m)

Draft (max)

13.1 ft (4 m)

Air draft

98.4 ft (30 m)

Displacement

39,683 lb (18,000 kg)

Ballast

—

Cabins

3–4

Heads

—

Berths

—

Sail Plan

Main sail

1,550 ft² (144 m²)

Jib

635 ft² (59 m²)

Genoa

958 ft² (89 m²)

Sail area

—

Downwind sail area

3,122 ft² (290 m²)

Rig type

—

Engine and Tanks

Engine

80 hp (Yanmar)

Engine count

2

Engine manufacturer

Yanmar

Propulsion type

—

Fuel capacity

—

Fresh water capacity

—

Black water capacity

—

Construction

Mast material

—

Hull material

—

Deck material

—

Keel type

daggerboards

Rudder type

—

Steering wheels

—

Builder's Own Figures

Self-Tacking Jib

59 m2

Bridge Deck Clearance

1,017 mm

Storm Jib

23 m2

Propulsion

2x Yanmar Diesels 80hp

Helm

Aft Helm / Forward Helm (same figures)

Displacement Max Load

24,750 kg

Hull Beam

1.7 m

Classification

CE Category A, Module B

Fractional Reacher

195 m2

Spinnaker

290 m2

Solent

89 m2

About HH Catamarans

Semi-custom

Performance cruising catamaran brand of the Hudson Yacht Group, formed in 2012 and built at its own yards in Xiamen, China and Cebu, Philippines.

The HH Catamarans Range

Every model HH Catamarans publishes, by length — where this one sits in the range.

1. HH8888 ft
2. HH66· this model65.9 ft
3. HH5255.9 ft
4. HH4450.2 ft
5. HH4649 ft
