Name: Eighty 2
Brand: Lagoon

Design

Designer: Nauta Design
Naval architect: VPLP Design

Summary

Sailing CatamaranSailCE A

Length overall: 81.9 ft
Beam: 36.1 ft
Draft: 6.2 ft
Air draft: 120.1 ft
Sail area (upwind): 3,638 ft²
Cabins: 4–5
Berths: 8–16
Steering wheels: 2

* A standard reference image, not the actual boat — shown to help visualise this model's published dimensions.

Best Suited For

Bluewater Cruising
From the published figures: CE Category A · LOA 24.97 m · fresh water 1600 L

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Sail area / displacement

How much sail the boat carries for its weight — its power in light air.

not published: displacement

How it is worked out

sail area (ft²) ÷ (displacement as ft³ of seawater)^⅔

Displacement / length

How heavy the boat is for its waterline length. Lower is lighter and quicker; higher is steadier and roomier.

not published: displacement, waterline length

How it is worked out

displacement (long tons) ÷ (0.01 × waterline length in ft)³

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Fuel and water on one scale: a tank twice the height holds twice as much.

Fuel740 gal
Water423 gal
26 gal of water per berth

Design Category

Certified CE design category A (Ocean): the wind and waves the EU Recreational Craft Directive says this boat is designed to take.

D
Sheltered waters
Wind
up to Beaufort 4
Waves
up to 0.3 m
C
Inshore
Wind
up to Beaufort 6
Waves
up to 2 m
B
Offshore
Wind
up to Beaufort 8
Waves
up to 4 m
AThis boat
Ocean
Wind
above Beaufort 8
Waves
above 4 m

Design limits set by the EU Recreational Craft Directive (2013/53/EU), in significant wave height. A category covers the conditions of those below it. It is the limit the boat was designed to, not a promise that it is safe in any conditions within it — that judgement stays with the skipper.

Dimensions

LOA: 81.9 ft (24.97 m)
Hull length: 78.4 ft (23.91 m)
LWL: —
Beam: 36.1 ft (11 m)
Draft (min): 6.2 ft (1.9 m)
Draft (max): —
Air draft: 120.1 ft (36.6 m)
Displacement: —
Ballast: —
Cabins: 4–5
Heads: —
Berths: 8–16

Sail Plan

Main sail: —
Jib: —
Genoa: —
Sail area: 3,638 ft² (338 m²)
Downwind sail area: —
Rig type: —

Engine and Tanks

Engine: 230 hp (John Deere)
Engine count: 2
Engine manufacturer: John Deere
Propulsion type: —
Fuel capacity: 740 gal (2,800 L)
Fresh water capacity: 423 gal (1,600 L)
Black water capacity: —

Construction

Mast material: —
Hull material: —
Deck material: —
Keel type: —
Rudder type: —
Steering wheels: 2

Builder's Own Figures

Launch: Revealed at the Cannes Yachting Festival 2025 (catamarans-lagoon.com/boats/eighty-2: 'At the 2025 Cannes Boat Show, the Lagoon Eighty 2 was revealed')
