ICE 70 Suite

Name: ICE 70 Suite
Brand: ICE Yachts

In production

1 / 8

ICE70-SUITE-armatoriale-01-wb — ICE Yachts

Design

Naval architect: Felci Yacht Design

Summary

Sailing MonohullSail

Length overall: 69.9 ft
Beam: 18.9 ft
Draft: 9–14.8 ft
Displacement: 59,525 lb
Sail area (upwind): 2,852 ft²
Cabins: 3

* A standard reference image, not the actual boat — shown to help visualise this model's published dimensions.

Best Suited For

Performance Cruising
From the published figures: SA/D 29.9 (upwind 265 m², displacement 27000 kg) · 3 cabins
Liveaboard
From the published figures: LOA 21.3 m · 3 cabins · fresh water 1080 L

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Sail area / displacement

How much sail the boat carries for its weight — its power in light air.

29.9· Racing

How it is worked out

sail area (ft²) ÷ (displacement as ft³ of seawater)^⅔

published upwind sail area

Displacement / length

How heavy the boat is for its waterline length. Lower is lighter and quicker; higher is steadier and roomier.

87· Ultralight

How it is worked out

displacement (long tons) ÷ (0.01 × waterline length in ft)³

Ballast ratio

The share of the weight carried in the keel — a rough guide to stiffness, though how deep that weight sits matters as much.

24· Low

How it is worked out

ballast ÷ displacement × 100

Comfort ratio

Ted Brewer's measure of how gently a boat moves in a seaway. Higher means a slower, easier motion.

26.7· Coastal

How it is worked out

displacement (lb) ÷ (0.65 × (0.7 × LWL + 0.3 × LOA) × beam^1.333), lengths in ft

Capsize screening

A guide from the inquiry after the 1979 Fastnet race: below 2 was taken as suited to ocean passages. It ignores hull shape and where the ballast sits.

1.94· Below 2

How it is worked out

beam (ft) ÷ (displacement as ft³ of seawater)^⅓

Hull speed

Roughly the speed a displacement hull reaches before it has to climb its own bow wave.

11.0 kn

How it is worked out

1.34 × √(waterline length in ft), in knots

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Fuel and water on one scale: a tank twice the height holds twice as much.

Fuel264 gal
Water285 gal

Dimensions

LOA: 69.9 ft (21.3 m)
Hull length: —
LWL: 67.3 ft (20.52 m)
Beam: 18.9 ft (5.76 m)
Draft (min): 9 ft (2.75 m)
Draft (max): 14.8 ft (4.5 m)
Air draft: —
Displacement: 59,525 lb (27,000 kg)
Ballast: 14,550 lb (6,600 kg)
Cabins: 3
Heads: —
Berths: —

Sail Plan

Main sail: 1,615 ft² (150 m²)
Jib: —
Genoa: —
Sail area: 2,852 ft² (265 m²)
Downwind sail area: 4,176 ft² (388 m²)
Rig type: —

Engine and Tanks

Engine: 195–230 hp (Yanmar)
Engine count: —
Engine manufacturer: Yanmar
Propulsion type: —
Fuel capacity: 264 gal (1,000 L)
Fresh water capacity: 285 gal (1,080 L)
Black water capacity: 53 gal (200 L)

Construction

Mast material: —
Hull material: —
Deck material: —
Keel type: —
Rudder type: —
Steering wheels: —

Builder's Own Figures

Grey water tank: 285 lt
Jib: 115 m²
Engine: Yanmar Diesel 4LV 195 (230hp opt.)
Engine power basis: hp per engine as printed (single engine; options as range)
Displacement basis: as printed (27,00 t)
Draft as printed: 2,75/4,50 m (keel Up / keel Down)
Sail area basis: main 150 + jib 115 m² as printed

Figures read fromiceyachts.it/ice-70-suite/· datiread 9/18/2026

About ICE Yachts

Semi-custom

Italian builder of carbon-epoxy performance cruisers from Salvirola near Cremona — fourteen Felci-designed monohulls from the 15.8-metre ICE 52 to the 24-metre ICE 80, plus the ICE Cat sixty four and seventytwo catamarans by Micheletti+Partners, all infused in carbon and glass with carbon rigs.

Visit brand page
