Bali CATSMART

Design

Designer

Olivier Poncin

Naval architect

Xavier Faÿ

Interior designer

PIATON BERCO

Summary

Best Suited For

• Bluewater Cruising

  From the published figures: CE Category A · LOA 12.08 m

• Short-Handed

  From the published figures: LOA 12.08 m · upwind 100 m²

• Liveaboard

  From the published figures: LOA 12.08 m · 4 cabins · 2 heads

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Dimensions

LOA

39.6 ft (12.08 m)

Hull length

37.2 ft (11.34 m)

LWL

36.7 ft (11.18 m)

Beam

21.2 ft (6.46 m)

Draft (min)

3.6 ft (1.11 m)

Draft (max)

3.6 ft (1.11 m)

Air draft

—

Displacement

19,621 lb (8,900 kg)

Ballast

—

Cabins

2–4

Heads

2

Berths

—

Sail Plan

Main sail

—

Jib

—

Genoa

—

Sail area

1,076 ft² (100 m²)

Downwind sail area

—

Rig type

—

Engine and Tanks

Engine

—

Engine count

—

Engine manufacturer

—

Propulsion type

—

Fuel capacity

—

Fresh water capacity

—

Black water capacity

—

Construction

Mast material

—

Hull material

—

Deck material

—

Keel type

—

Rudder type

—

Steering wheels

—

Builder's Own Figures

Surface utilisable

66 m²

Eau noire

2 x 55 L

Surface de voile standard

76 m²

Déplacement en charge maxi

12 t

CE persons

category A 8; category B 10; category C 16; category D 20 (certified persons, not guests)

Displacement at maximum load

27650 lbs

Unit basis

the page prints imperial units; converted (ft/in -> m, lbs -> kg, sq ft -> m2)

Displacement basis

empty weight 19667 lbs as printed -> 8921 kg

Sail area basis

maximum upwind sail area 1076 sq ft -> 100.0 m2; standard sail area 818 sq ft

Films of this model from the builder's official YouTube channel (Bali Catamarans). They are the builder's own; the figures above are the reference.

Videos whose title names the Bali CATSMART, from the channel the builder's site links; last checked 9/30/2026. Playing one loads YouTube's player, which may set cookies.

About Bali

Volume production

French catamaran brand founded in 2014 by Olivier Poncin, designed by Catana Group's Research and Innovation department, known for its opening bow door concept.

The Bali Range

Every model Bali publishes, by length — where this one sits in the range.

1. Bali 7.073.9 ft
2. Bali 5.857.9 ft
3. Bali 5.253.8 ft
4. Bali 4.647 ft
5. Bali 4.345.1 ft
6. Bali 4.444.3 ft
7. Bali 4.242.2 ft
8. Bali CATSPACE40.5 ft
9. Bali CATSMART· this model39.6 ft
