K6-68

Design

Designer

Simonis Voogd Yacht Design

Summary

Best Suited For

• Bluewater Cruising

  From the published figures: CE Category A · LOA 20.75 m · fresh water 1650 L

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

68.1 ft (20.75 m)

Hull length

—

LWL

63.3 ft (19.3 m)

Beam

30.8 ft (9.4 m)

Draft (min)

5.2 ft (1.6 m)

Draft (max)

12.3 ft (3.75 m)

Air draft

105 ft (32 m)

Displacement

51,809 lb (23,500 kg)

Ballast

—

Cabins

—

Heads

—

Berths

—

Sail Plan

Main sail

—

Jib

—

Genoa

—

Sail area

—

Downwind sail area

—

Rig type

—

Engine and Tanks

Engine

—

Engine count

2

Engine manufacturer

Yanmar

Propulsion type

twin diesel saildrives with Integrel E-Drives (hybrid)

Fuel capacity

436 gal (1,650 L)

Fresh water capacity

436 gal (1,650 L)

Black water capacity

—

Construction

Mast material

—

Hull material

carbon (all-carbon construction)

Deck material

—

Keel type

—

Rudder type

—

Steering wheels

—

Builder's Own Figures

Lengths

one K6 design in two purpose-built lengths, 64' and 68'; the renders shown are the 64' version

Headroom

salon 2.1 m minimum, hulls 2 m minimum

Draft

boards up 1.6 m (standard rudder), centreboards down 3.75 m

Bridge deck clearance

1 m

Beam of hulls

2.6 m

Mast length

29 m (Performance) / 30 m (Turbo), coachroof stepped

Boards

carbon centreboards (daggerboards optional)

Sail areas

Performance rig: mainsail 156 m² (furling boom) or 162 m² (slab reefing), J2/jib 99 m², J0 155 m², storm staysail 33 m², spinnaker A2 409 m²; Turbo rig: mainsail 176/183 m², jib 102 m², J0 165 m², spinnaker A2 446 m²

Engines

twin Yanmar 110 diesel engines, ZF SD15 sail drives and Integrel E-Drives (hybrid electric motoring and power generation)

Air draft

mast clearance above water 32 m with the Performance rig, 33 m with the Turbo rig

Rig

coachroof-stepped high-modulus carbon mast; Performance or Turbo rig and sail plan

Displacement basis

target lightship 23,500 kg as printed; realistic cruising weight 29,500 kg

Status

tooling construction began in 2026 (yard update, April 2026)

Unit basis

metric and imperial printed side by side in the specification images; metric stored

Layouts & Drawings

2 drawings from the builder's page: general arrangement, sail plan, profile.

•

  K68_Performance — Kinetic Catamarans

•

  K68_Turbo — Kinetic Catamarans

About Kinetic Catamarans

Semi-custom

Builder of all-carbon performance cruising catamarans, founded in 2018 — the 16.5-metre KC54 and the new K6 in 64-foot and 68-foot lengths, designed by Simonis Voogd in the Netherlands and built in Kinetic's own yard in Knysna, South Africa.

Kinetic Catamarans was founded in 2018 and, in its own words, has established itself as a creator of innovative, quality performance catamarans. It is a US company with its yard in Knysna, South Africa, and a joint venture between two keen sailors: Bob Hayward, a successful US real estate developer and entrepreneur, and Leon Scheepers, a respected South African boatbuilder with wide experience of multihull production. Their vision is luxury performance cruising catamarans of the highest quality and reliability, and their philosophy that time on the water is precious: the boats use all-carbon construction for its weight saving and strength, carry performance carbon rigs and sail plans, and are set up for short-handed sailing, with only leading equipment and suppliers, attention to detail and after-sales support meant to take the complexity out of owning a boat of this kind. The designs come from Simonis Voogd Design BV in the Netherlands; the electrical systems are designed with Cay Electronics (USA, Tortola), the rig and sailing set-up with Rigging Projects (UK, the Netherlands), and the sails by North Sails.

The Kinetic Catamarans Range

Every model Kinetic Catamarans publishes, by length — where this one sits in the range.

1. K6-68· this model68.1 ft
2. K6-6464 ft
3. KC5454.1 ft
