A96

Summary

Speed, Power & Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

95.4 ft (29.07 m)

Hull length

—

LWL

—

Beam

26 ft (7.92 m)

Draft (min)

5.8 ft (1.77 m)

Draft (max)

—

Air draft

—

Displacement

275,578 lb (125,000 kg)

Ballast

—

Cabins

5

Heads

—

Berths

—

Performance

Maximum speed

21 kn

Cruising speed

18 kn

Range

—

Guests

10

Crew

5

Engine and Tanks

Engine

800–1000 hp (Volvo Penta)

Engine count

4

Engine manufacturer

Volvo Penta

Propulsion type

Volvo Penta IPS pods

Fuel capacity

3,355 gal (12,700 L)

Fresh water capacity

528 gal (2,000 L)

Black water capacity

185 gal (700 L)

Construction

Hull material

—

Deck material

—

Rudder type

—

Steering wheels

—

Builder's Own Figures

Maximum Speed

± 21 (std) 23 / 24 (one figure per engine option, standard first)

Grey water

750 L

Hull type

Semi-Displacement

Solar panel energy

± 4,5 Kw

Cruise Speed

± 18 (std) 19 / 20 (one figure per engine option, standard first)

Guest beds

10 beds in 5 cabins

Main engines

N.4 VOLVO PENTA IPS 1.050 - 800 HP (std) 1.200 - 900 HP (opt) 1.350 - 1.000 HP (opt)

Crew beds

5 beds in 3 cabins

Hull length as printed

23,95 m / 78'07' (5 m shorter than the overall length; not entered)

Engine power basis

per engine as printed (min/max across the engine options)

Displacement basis

under full load, as printed (125 tons / 276.000 lb standard configuration)

Layouts & Drawings

4 drawings from the builder's page: general arrangement, sail plan, profile.

•

  Profile-A96-scaled — Arcadia Yachts

•

  UPPER-DECK-A96-scaled — Arcadia Yachts

•

  MAIN-DECK-A96-scaled — Arcadia Yachts

•

  LOWER-DECK-A96-scaled — Arcadia Yachts

About Arcadia Yachts

Semi-custom

Neapolitan builder of glass-walled, solar-roofed semi-displacement motor yachts — seven models in the A and Sherpa collections, from the 18.7-metre Sherpa 60 to the 35-metre A115, built at Torre Annunziata on the Bay of Naples.

Arcadia Yachts places its roots in the culture around Naples — from ancient Pompeii and the Maritime Republic of Amalfi to the Neapolitan Renaissance and the city's cooking — and says its yachts carry on that long love story with the sea. The page marks one date: 22 December 2009, the launch of the first Arcadia 85, bound for Düsseldorf, under a line from Ugo Pellegrino: 'When there's an idea, you're halfway through the journey.' The yard calls its approach the 'Yachting Renaissance', a way of cruising built around people rediscovering a more natural harmony with the sea, with large spaces and windows that open the boat to nature, which technology is meant to protect. The name comes from classical literature, where Arcadia was an idyllic land whose people lived in perfect harmony with nature.

The Arcadia Yachts Range

Every model Arcadia Yachts publishes, by length — where this one sits in the range.

1. A115114.8 ft
2. A105103.6 ft
3. A96· this model95.4 ft
4. A8585 ft
5. Sherpa 8080.7 ft
6. A8078.7 ft
7. Sherpa 6061.3 ft
