Numarine 22XP

Name: Numarine 22XP
Brand: Numarine

In production

1 / 10

numarine_web_banner_1650x2031px_22xp — Numarine

Summary

Motor MonohullInboard DieselCE B

Length overall: 74.1 ft
Beam: 19.7 ft
Maximum speed: 13 kn
Cruising speed: 11 kn
Range: 1200 nm
Guests: 8
Crew: 2
Displacement: 136,686 lb
Engine power: 425–1200 hp
Cabins: 3–4

* A standard reference image, not the actual boat — shown to help visualise this model's published dimensions.

Best Suited For

Bluewater Cruising
From the published figures: explorer · range 1200 nm
Liveaboard
From the published figures: LOA 22.6 m · 4 cabins
Coastal Cruising
From the published figures: CE Category B · LOA 22.6 m

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Speed, Power & Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Speed

Cruising speed11 kn
Top speed13 kn

Power to weight

Total engine power per tonne of published displacement — more means livelier acceleration for the hull. Drawn for motor yachts.

38.7 hp/t

2 × 1,200 hp · 62 t

Tanks

Fuel and water on one scale: a tank twice the height holds twice as much.

Fuel1,585 gal
Waternot published

Design Category

Certified CE design category B (Offshore): the wind and waves the EU Recreational Craft Directive says this boat is designed to take.

D
Sheltered waters
Wind
up to Beaufort 4
Waves
up to 0.3 m
C
Inshore
Wind
up to Beaufort 6
Waves
up to 2 m
BThis boat
Offshore
Wind
up to Beaufort 8
Waves
up to 4 m
A
Ocean
Wind
above Beaufort 8
Waves
above 4 m

Design limits set by the EU Recreational Craft Directive (2013/53/EU), in significant wave height. A category covers the conditions of those below it. It is the limit the boat was designed to, not a promise that it is safe in any conditions within it — that judgement stays with the skipper.

Dimensions

LOA: 74.1 ft (22.6 m)
Hull length: —
LWL: —
Beam: 19.7 ft (6 m)
Draft (min): 6 ft (1.84 m)
Draft (max): 6 ft (1.84 m)
Air draft: —
Displacement: 136,686 lb (62,000 kg)
Ballast: —
Cabins: 3–4
Heads: —
Berths: —

Performance

Maximum speed: 13 kn
Cruising speed: 11 kn
Range: 1200 nm
Guests: 8
Crew: 2

Engine and Tanks

Engine: 425–1200 hp (Cummins)
Engine count: 2
Engine manufacturer: Cummins
Propulsion type: —
Fuel capacity: 1,585 gal (6,000 L)
Fresh water capacity: —
Black water capacity: 198 gal (750 L)

Construction

Hull material: GRP
Deck material: —
Rudder type: —
Steering wheels: —

Builder's Own Figures

Engine option: Twin MAN D2868 LE 436 1200bhp (882Kw) @2300rpm Light Duty IMO TII
Range: 1,200 nm @ 8 knots
Gross tonnage: under 150 GT
Build time: 8 Months
Hull type: Displacement
Engine options: Twin MAN D2868 LE 436 1200bhp (882Kw) @2300rpm Light Duty IMO TII
Economic speed: 8 kn
Accommodation: 6 or 8 guests + 2 crew
Fresh water: page prints '1.1000 L / 290 gal' -- misprint, left empty
Superstructure material: GRP
Engines: Twin Cummins 425 HP INTERMITTENT DUTY
Cabins: 3 or 4 guest + 1 crew
Engine power basis: per engine; min = standard engine, max = largest option as printed
Displacement basis: full load

Figures read fromnumarine.com/yachts/22xp· PRINCIPAL SPECIFICATIONSread 9/13/2026

About Numarine

Semi-custom

Turkish builder of explorer yachts — the XP Series from the 22XP to the 47MXP and the XPC 38XPC/39MXPC — founded in 2002 by Ömer Malaz in Istanbul and building today at Gebze, Kocaeli.

Numarine was founded in Istanbul in 2002 by Ömer Malaz, who came from performance boating and set out to build explorer yachts offering more range, more comfort and more style than the type then allowed. The yard began with high-performance boats defined by engineering and striking design, and as the market turned towards long-range, self-sufficient cruising it narrowed its focus to explorer yachts alone. Close to 200 have been launched from Istanbul since, and they range from the 22XP to the 47MXP.
