Catalina 316

Summary

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

33 ft (10.06 m)

Hull length

31 ft (9.45 m)

LWL

26.5 ft (8.08 m)

Beam

11.6 ft (3.53 m)

Draft (min)

4.8 ft (1.45 m)

Draft (max)

6.3 ft (1.91 m)

Air draft

49.2 ft (15.01 m)

Displacement

12,000 lb (5,443 kg)

Ballast

3,999 lb (1,814 kg)

Cabins

—

Heads

1

Berths

—

Sail Plan

Main sail

—

Jib

—

Genoa

—

Sail area

—

Downwind sail area

—

Rig type

—

Engine and Tanks

Engine

21 hp (Yanmar)

Engine count

1

Engine manufacturer

Yanmar

Propulsion type

—

Fuel capacity

25 gal (95 L)

Fresh water capacity

41 gal (155 L)

Black water capacity

17 gal (64 L)

Construction

Mast material

—

Hull material

GRP (hand-laid fiberglass)

Deck material

—

Keel type

Shoal-draft bulb keel or fin keel

Rudder type

—

Steering wheels

1

Builder's Own Figures

Length of hull

31' 0"

Fin keel

draft 6' 3", ballast 4,000 lbs, displacement at half load 12,000 lbs

Sail area, total with standard 135% genoa

589 sq ft

Waterline to masthead

49' 3"

Length overall

33' 0"

Engine

Yanmar 3YM20, 21 HP Diesel (the standard-equipment list says 20 HP)

Rig dimensions

I=42' 9" J=12' 0" P=40' 3" E=13' 6"

Beam

11' 7"

Sail area, total with 100% foretriangle

530 sq ft

Shoal bulb keel

draft 4' 9", ballast 4,400 lbs, displacement at half load 12,400 lbs

Waterline length

26'6"

Propeller

3 Blade Dynajet 14 x 2

Holding tank as printed

17 gal

Water capacity as printed

41 gal total, including the water heater

Fuel capacity as printed

25 gal

Displacement basis

displacement at half load, fin keel version, as printed (12,000 lbs)

About Catalina Yachts

Volume production

American sailboat builder founded by Frank Butler in 1970, which calls itself America's largest sailboat builder — the 22 Sport and 22 Capri trailerables, the 276 Sport, the 6 Series 316, 356, 386 and 426 and the 445, from 7.3 to 13.5 metres, owned, designed and built in Largo, Florida.

Catalina's first model, the Catalina 22, was built in North Hollywood, California, in July 1969, when owner Frank Butler hoped to build a hundred boats; he founded Catalina Yachts in 1970 with the goal, the company says, of building good boats that are a good value. The Catalina 27 followed in March 1970 and the Catalina 30 in December 1974, and the 22 passed hull number 5,000 in 1975 and 10,000 in 1980, by then built at Catalina's East and West Coast plants and in England, Australia and Canada. In 1984 Catalina acquired Morgan Yachts in Largo, Florida, which became its Morgan Division, building cruising and charter boats and many Catalina models on the East Coast. The first Catalina 42 of 1989 delivered 100 hulls in its first year, and in 1990 the Catalina 30 reached hull 6,000 and the 22 hull 15,000. The 1990s brought the 270, 320, 400, 380 and 470, and in 1995 Frank Butler received SAIL's Industry Award for Leadership. In December 1998 he took Sharon Day, vice-president of sales, and Gerry Douglas, vice-president of engineering, as partners in his privately held company. The company says Sharon Day, who worked alongside Frank for 48 years, now leads a veteran team that carries his vision forward at what it calls America's largest sailboat builder.
