Faurby 570 DSvsKraken 58

Kraken 58 draws the least water, 7.5 ft — 0.7 ft less than Faurby 570 DS. Kraken 58 carries the most sail for its weight (SA/D 20.2, Performance); Faurby 570 DS the least (19.3, Cruiser). Only Kraken 58 meets the rule for Liveaboard.

Anyone with the link sees this comparison.

Key differences

Worked out from the published figures below — arithmetic, not opinion.

At a glance

Dark icons are the standard layout; faded ones are what the larger layout adds.

Length : beam is length divided by beam — the higher it is, the slimmer the hull. Multihulls read low by nature.

Model
f-57-exterior-02-2560x1440

Faurby Yachts

Faurby 570 DS
DJI_20250831134922_0089_D-scaled

Kraken Yachts

Kraken 58
Overview
BrandFaurby YachtsKraken Yachts
ModelFaurby 570 DSKraken 58
GenerationUnknownUnknown
Hull typeSailing MonohullSailing Monohull
PropulsionSailSail
Production statusIn productionIn production
Production start yearUnknownUnknown
Production end yearUnknownUnknown
DesignerUnknownUnknown
Dimensions
LOA57.1 ft58 ft
Hull lengthUnknownUnknown
Beam16.7 ft17.1 ft
Draft8.2 ft7.5 ft
Displacement59,304 lb60,627 lb
Accommodation
CabinsUnknown4
HeadsUnknownUnknown
BerthsUnknownUnknown
Performance & Rig
Main sail1,023 ft²1,174 ft²
Jib807 ft²772 ft²
GenoaUnknown1,302 ft²
Upwind sail areaUnknown1,947 ft²
Downwind sail areaUnknownUnknown
Engine powerUnknown150 hp
Engine countUnknown1
Materials
Hull materialUnknownUnknown
Deck materialUnknownUnknown
Mast materialUnknownUnknown
Keel typeUnknownZero Keel (integral, part of the hull)
Rudder typeUnknownAlpha Rudder (skeg-hung)
Sources

Figures read fromfaurby.dk/yachts/faurby-570-ds· Specificationsread 9/13/2026

Figures read fromkrakenyachts.com/kraken58/· Design specificationread 9/13/2026

Size, to scale

Each boat's published length and beam seen from above, and its mast height and draft from the side, all drawn on one scale.

From above — length × beam
0 ft10 ft20 ft30 ft40 ft50 ftKraken 58: 58 ft × 17.1 ftFaurby 570 DS: 57.1 ft × 16.7 ftKraken 5858 ft × 17.1 ftFaurby 570 DS57.1 ft × 16.7 ft

Outlines are schematic; the dimensions are the builder's.

From the side — height above and depth below the water
WaterlinePerson, 5.9 ftFaurby 570 DS: air draft not published / 8.2 ftair draft not published8.2 ftFaurby 570 DSKraken 58: 98.4 ft / 7.5 ft98.4 ft7.5 ftKraken 58

Drawings side by side

Each boat's layouts, profiles and sail plans as its builder published them. Step through each column to line up the drawings you want to compare.

No drawings collected yet for Faurby 570 DS.

Speed, power & tanks

What the builders publish about how fast, how strong and how far — each figure on one scale for every boat.

Tanks

One scale per liquid across every boat: a tank twice the height holds twice as much.

  • Faurby 570 DS

    Fuel264 gal
    Water264 gal

  • Kraken 58

    Fuel423 gal
    Water251 gal

How they sail, in numbers

Classic yacht-design ratios worked out from each builder's published figures. They compare boats; they don't grade them.

Sail area / displacement

How much sail the boat carries for its weight — its power in light air.

ModestCruiserPerformanceRacing162024Faurby 570 DS: 19.3Kraken 58: 20.2
  • Faurby 570 DS19.3· Cruiser
  • Kraken 5820.2· Performance
How it is worked out

sail area (ft²) ÷ (displacement as ft³ of seawater)^⅔

Faurby 570 DS: mainsail + jib, added up

Kraken 58: published upwind sail area

Displacement / length

How heavy the boat is for its waterline length. Lower is lighter and quicker; higher is steadier and roomier.

UltralightLightModerateHeavyVery heavy100180270350Faurby 570 DS: 190Kraken 58: 193
  • Faurby 570 DS190· Moderate
  • Kraken 58193· Moderate
How it is worked out

displacement (long tons) ÷ (0.01 × waterline length in ft)³

Ballast ratio

The share of the weight carried in the keel — a rough guide to stiffness, though how deep that weight sits matters as much.

LowModerateHigh3040Faurby 570 DS: 32Kraken 58: 37
  • Faurby 570 DS32· Moderate
  • Kraken 5837· Moderate
How it is worked out

ballast ÷ displacement × 100

Comfort ratio

Ted Brewer's measure of how gently a boat moves in a seaway. Higher means a slower, easier motion.

LightCoastalModerate offshoreHeavy offshoreVery heavy20304050Faurby 570 DS: 40.0Kraken 58: 39.6
  • Faurby 570 DS40.0· Heavy offshore
  • Kraken 5839.6· Moderate offshore
How it is worked out

displacement (lb) ÷ (0.65 × (0.7 × LWL + 0.3 × LOA) × beam^1.333), lengths in ft

Capsize screening

A guide from the inquiry after the 1979 Fastnet race: below 2 was taken as suited to ocean passages. It ignores hull shape and where the ballast sits.

Below 22 and above2Faurby 570 DS: 1.72Kraken 58: 1.74
  • Faurby 570 DS1.72· Below 2
  • Kraken 581.74· Below 2
How it is worked out

beam (ft) ÷ (displacement as ft³ of seawater)^⅓

Hull speed

Roughly the speed a displacement hull reaches before it has to climb its own bow wave.

  • Faurby 570 DS9.6 kn
  • Kraken 589.7 kn
How it is worked out

1.34 × √(waterline length in ft), in knots

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.
