CNB 88vsNautor Swan Swan 88

Swan 88 draws the least water, 9.8 ft — 2.5 ft less than CNB 88. Only Swan 88 meets the rule for Performance Cruising.

Anyone with the link sees this comparison.

Key differences

Worked out from the published figures below — arithmetic, not opinion.

At a glance

Dark icons are the standard layout; faded ones are what the larger layout adds.

Length : beam is length divided by beam — the higher it is, the slimmer the hull. Multihulls read low by nature.

A figure marked with a quote mark was read from the builder's page. Open it for the exact line, the page and the date.

Model
CNB 88 sailing

CNB Yacht Builders

CNB 88
Nautor Swan Swan 88

Nautor Swan

Swan 88
Overview
BrandCNB Yacht BuildersNautor Swan
ModelCNB 88Swan 88
GenerationUnknownUnknown
Hull typeSailing MonohullSailing Monohull
PropulsionSailSail
Production statusIn productionIn production
Production start yearUnknownUnknown
Production end yearUnknownUnknown
DesignerUnknownUnknown
Dimensions
LOA92.8 ft92.7 ft
Hull length87.9 ft87.1 ft
Beam22.1 ft22.3 ft
Draft12.3 ft9.8 ft–15.1 ft
Displacement127,868 lb119,270 lb
Accommodation
Cabins43–4
HeadsUnknownUnknown
BerthsUnknownUnknown
Performance & Rig
Main sail2,293 ft²2,542 ft²
JibUnknown2,115 ft²
Genoa2,024 ft²Unknown
Upwind sail areaUnknown4,658 ft²
Downwind sail area6,351 ft²Unknown
Engine power225 hp230 hp
Engine count11
Materials
Hull materialUnknownUnknown
Deck materialUnknownUnknown
Mast materialUnknownUnknown
Keel typeUnknownUnknown
Rudder typeUnknownUnknown
Sources

10 of 11 figures here carry the builder's own words

9 of 11 figures here carry the builder's own words

Size, to scale

Each boat's published length and beam seen from above, and its mast height and draft from the side, all drawn on one scale.

From above — length × beam
0 ft10 ft20 ft30 ft40 ft50 ft60 ft70 ft80 ft90 ftSwan 88: 92.7 ft × 22.3 ftCNB 88: 92.8 ft × 22.1 ftCNB 8892.8 ft × 22.1 ftSwan 8892.7 ft × 22.3 ft

Outlines are schematic; the dimensions are the builder's.

From the side — height above and depth below the water
WaterlinePerson, 5.9 ftCNB 88: 124.5 ft / 12.3 ft124.5 ft12.3 ftCNB 88Swan 88: air draft not published / 15.1 ftair draft not published15.1 ftSwan 88

Drawings side by side

Each boat's layouts, profiles and sail plans as its builder published them. Step through each column to line up the drawings you want to compare.

No drawings collected yet for CNB 88.

Speed, power & tanks

What the builders publish about how fast, how strong and how far — each figure on one scale for every boat.

Tanks

One scale per liquid across every boat: a tank twice the height holds twice as much.

  • CNB 88

    Fuel793 gal
    Water476 gal

  • Swan 88

    Fuel740 gal
    Water396 gal

How they sail, in numbers

Classic yacht-design ratios worked out from each builder's published figures. They compare boats; they don't grade them.

Sail area / displacement

How much sail the boat carries for its weight — its power in light air.

ModestCruiserPerformanceRacing162024CNB 88: 27.2Swan 88: 30.8▶
  • CNB 8827.2· Racing
  • Swan 8830.8· Racing
How it is worked out

sail area (ft²) ÷ (displacement as ft³ of seawater)^⅔

CNB 88: mainsail + genoa, added up

Swan 88: published upwind sail area

Displacement / length

How heavy the boat is for its waterline length. Lower is lighter and quicker; higher is steadier and roomier.

UltralightLightModerateHeavyVery heavy100180270350CNB 88: 107Swan 88: 98
  • CNB 88107· Light
  • Swan 8898· Ultralight
How it is worked out

displacement (long tons) ÷ (0.01 × waterline length in ft)³

Ballast ratio

The share of the weight carried in the keel — a rough guide to stiffness, though how deep that weight sits matters as much.

LowModerateHigh3040CNB 88: 28Swan 88: 28
  • CNB 8828· Low
  • Swan 8828· Low
How it is worked out

ballast ÷ displacement × 100

Comfort ratio

Ted Brewer's measure of how gently a boat moves in a seaway. Higher means a slower, easier motion.

LightCoastalModerate offshoreHeavy offshoreVery heavy20304050CNB 88: 37.4Swan 88: 34.5
  • CNB 8837.4· Moderate offshore
  • Swan 8834.5· Moderate offshore
How it is worked out

displacement (lb) ÷ (0.65 × (0.7 × LWL + 0.3 × LOA) × beam^1.333), lengths in ft

Capsize screening

A guide from the inquiry after the 1979 Fastnet race: below 2 was taken as suited to ocean passages. It ignores hull shape and where the ballast sits.

Below 22 and above2CNB 88: 1.76Swan 88: 1.81
  • CNB 881.76· Below 2
  • Swan 881.81· Below 2
How it is worked out

beam (ft) ÷ (displacement as ft³ of seawater)^⅓

Hull speed

Roughly the speed a displacement hull reaches before it has to climb its own bow wave.

  • CNB 8812.1 kn
  • Swan 8812.1 kn
How it is worked out

1.34 × √(waterline length in ft), in knots

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.
