Speed
- Cruising speednot published
- Top speed37 kn
1 / 10
Design
- Designer
- Jarkko Jämsén
Summary
- Length overall
- 43.3 ft
- Beam
- 14.1 ft
- Maximum speed
- 37 kn
- Displacement
- 12,787 lb
- Engine power
- 250–350 hp
- Cabins
- 1
* A standard reference image, not the actual boat — shown to help visualise this model's published dimensions.
Best Suited For
- Coastal Cruising
From the published figures: CE Category B · LOA 13.2 m
Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.
Speed, Power & Tanks
What the builder publishes about how fast, how strong and how much the boat carries.
Power to weight
Total engine power per tonne of published displacement — more means livelier acceleration for the hull. Drawn for motor yachts.
181 hp/t
3 × 350 hp · 5.8 t
Tanks
Fuel and water on one scale: a tank twice the height holds twice as much.
- Fuel251 galWater34 gal
11 gal of water per berth
Design Category
Certified CE design category B (Offshore): the wind and waves the EU Recreational Craft Directive says this boat is designed to take.
- D
Sheltered waters
- Wind
- up to Beaufort 4
- Waves
- up to 0.3 m
- C
Inshore
- Wind
- up to Beaufort 6
- Waves
- up to 2 m
- BThis boat
Offshore
- Wind
- up to Beaufort 8
- Waves
- up to 4 m
- A
Ocean
- Wind
- above Beaufort 8
- Waves
- above 4 m
Design limits set by the EU Recreational Craft Directive (2013/53/EU), in significant wave height. A category covers the conditions of those below it. It is the limit the boat was designed to, not a promise that it is safe in any conditions within it — that judgement stays with the skipper.
A figure marked with a quote mark was read from the builder's page. Open it for the exact line, the page and the date.
Dimensions
- LOA
- 43.3 ft (13.2 m)
- Hull length
- —
- LWL
- 35.1 ft (10.7 m)
- Beam
- 14.1 ft (4.3 m)
- Draft (min)
- 2.8 ft (0.86 m)
- Draft (max)
- —
- Air draft
- —
- Displacement
- 12,787 lb (5,800 kg)
- Ballast
- —
- Cabins
- 1
- Heads
- —
- Berths
- 2–3
Performance
- Maximum speed
- 37 kn
- Cruising speed
- —
- Range
- —
- Guests
- —
- Crew
- —
Engine and Tanks
- Engine
- 250–350 hp
- Engine count
- 3
- Engine manufacturer
- —
- Propulsion type
- outboard
- Fuel capacity
- 251 gal (950 L)
- Fresh water capacity
- 34 gal (130 L)
- Black water capacity
- —
Construction
- Hull material
- GRP
- Deck material
- —
- Rudder type
- —
- Steering wheels
- —
Builder's Own Figures
- Hull Design
- Twin stepped V 20° Hull
Figures read fromthe builder's page
Brochure
Download the official Swan Shadow brochure (PDF)About Nautor Swan
Premium production
Finnish builder of luxury sailing yachts, founded in 1966 in Pietarsaari and known worldwide as Nautor Swan.
Oy Nautor AB was founded in 1966 by Pekka Koskenkylä at Pietarsaari, Finland, on centuries of Finnish boatbuilding and a wish to build high-performance sailing yachts of high quality. The first was the Swan 36, whose glass-reinforced hull came with a number of other innovations: it matched the traditional wooden yacht for performance and safety while steering more steadily, weighing less and offering more room below. Sparkman & Stephens drew roughly the first thousand Swans, the Swan 38 and Swan 47 among them, and the larger, seagoing Swan 55 and Swan 65 followed -- one of them, Sayula II, winning the first Whitbread Round the World Race in 1973-74. Ron Holland designed five yachts between 1978 and 1981, including the Swan 37, 39 and 42, and Germán Frers became the principal designer through the 1980s, later opening the one-design racing division with the Swan 45 in 2001 and the ClubSwan 42 in 2005. More than 2,350 yachts between 28 and 131 feet have been built in six decades. Everything is made at Pietarsaari, where engineering sits beside production, and the range now runs across six lines: Swan, Swan Maxi, ClubSwan, Swan Alloy, SwanScape and the motor yacht division Swan Shadow.
Visit brand pageThe Nautor Swan Range
Every model Nautor Swan publishes, by length — where this one sits in the range.
- Swan Arrow76.1 ft
- Swan Shadow· this model43.3 ft
- Swan OverShadow42.7 ft
