ClubSwan 50

Design

Designer

Juan Kouyoumdijan

Naval architect

Juan Kouyoumdjian

Interior designer

Michele Bönan

Summary

Sailing Ratios

Classic yacht-design ratios worked out from the builder's published figures, each shown against the bands designers read it by.

Most builders publish a light displacement. The ratios were defined on a loaded boat, so every boat here reads a little lighter than a surveyor's figure would — all alike, which keeps them comparable.

Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

54.9 ft (16.74 m)

Hull length

50 ft (15.24 m)

LWL

45.9 ft (14 m)

Beam

13.8 ft (4.2 m)

Draft (min)

7.2 ft (2.2 m)

Draft (max)

11.5 ft (3.5 m)

Air draft

—

Displacement

18,188 lb (8,250 kg)

Ballast

7,606 lb (3,450 kg)

Cabins

2–3

Heads

2

Berths

—

Sail Plan

Main sail

1,001 ft² (93 m²)

Jib

—

Genoa

—

Sail area

—

Downwind sail area

2,530 ft² (235 m²)

Rig type

—

Engine and Tanks

Engine

40 hp (Volvo)

Engine count

1

Engine manufacturer

Volvo

Propulsion type

—

Fuel capacity

45 gal (170 L)

Fresh water capacity

63 gal (240 L)

Black water capacity

—

Construction

Mast material

—

Hull material

carbon fibre

Deck material

—

Keel type

—

Rudder type

—

Steering wheels

—

Builder's Own Figures

Service battery

100 Ah

E

7.23 m

Engine starting battery

23 Ah

Engine power

29 kW

Black water

40 l

P

20.04 m

Fore triangle

65 m2

Shore power

230 V 30 A

J

6.30 m

I

19.88 m

Layouts & Drawings

1 drawing from the builder's page: general arrangement, sail plan, profile.

•

  ClubSwan 50 Sail Plan revB — Nautor Swan

Brochure

About Nautor Swan

Premium production

Finnish builder of luxury sailing yachts, founded in 1966 in Pietarsaari and known worldwide as Nautor Swan.

Oy Nautor AB was founded in 1966 by Pekka Koskenkylä at Pietarsaari, Finland, on centuries of Finnish boatbuilding and a wish to build high-performance sailing yachts of high quality. The first was the Swan 36, whose glass-reinforced hull came with a number of other innovations: it matched the traditional wooden yacht for performance and safety while steering more steadily, weighing less and offering more room below. Sparkman & Stephens drew roughly the first thousand Swans, the Swan 38 and Swan 47 among them, and the larger, seagoing Swan 55 and Swan 65 followed -- one of them, Sayula II, winning the first Whitbread Round the World Race in 1973-74. Ron Holland designed five yachts between 1978 and 1981, including the Swan 37, 39 and 42, and Germán Frers became the principal designer through the 1980s, later opening the one-design racing division with the Swan 45 in 2001 and the ClubSwan 42 in 2005. More than 2,350 yachts between 28 and 131 feet have been built in six decades. Everything is made at Pietarsaari, where engineering sits beside production, and the range now runs across six lines: Swan, Swan Maxi, ClubSwan, Swan Alloy, SwanScape and the motor yacht division Swan Shadow.

The Nautor Swan Range

Every model Nautor Swan publishes, by length — where this one sits in the range.

1. Swan 7377.7 ft
2. Swan 6571.4 ft
3. Swan 5862.7 ft
4. Swan 5558.2 ft
5. Swan 5155.4 ft
6. ClubSwan 50· this model54.9 ft
7. ClubSwan 4347.8 ft
8. ClubSwan 3636.1 ft
9. ClubSwan 2835.1 ft
