34O

Summary

Best Suited For

• Coastal Cruising

  From the published figures: CE Category B · LOA 12.06 m

Tags are derived from certified class, length, sail area, accommodation and tankage using the criteria described on the Sources page; an editor may add or remove one.

Speed, Power & Tanks

What the builder publishes about how fast, how strong and how much the boat carries.

Dimensions

LOA

39.6 ft (12.06 m)

Hull length

—

LWL

—

Beam

11.9 ft (3.63 m)

Draft (min)

2.1 ft (0.64 m)

Draft (max)

—

Air draft

11.7 ft (3.58 m)

Displacement

16,998 lb (7,710 kg)

Ballast

—

Cabins

—

Heads

—

Berths

—

Performance

Maximum speed

44.7 kn

Cruising speed

—

Range

—

Guests

—

Crew

—

Engine and Tanks

Engine

300–400 hp (Mercury)

Engine count

2

Engine manufacturer

Mercury

Propulsion type

Outboard

Fuel capacity

242 gal (916 L)

Fresh water capacity

60 gal (227 L)

Black water capacity

36 gal (136 L)

Construction

Hull material

GRP (vacuum-infused, PVC foam-cored)

Deck material

—

Rudder type

—

Steering wheels

—

Builder's Own Figures

Diesel tank

25 US Gallons (95 L)

Standards

Designed to ABYC, NMMA, USCG and CE Category B standards

Performance, Twin Mercury V8 Verado - 300 mHP

top speed 37 kn

Engine options

Twin Mercury V10 400HP; Twin Mercury V8 300HP

Fuel basis

gasoline tank for the outboards

Displacement basis

full load, as printed on the standard equipment sheet (17,000 lbs 7.71 t)

Draft basis

hull draft (outboards up), as the standard equipment sheet says

Top speed basis

top row (6386 rpm) in the builder's performance report, Twin Mercury V10 Verado - 400 mHP, Back Cove 34O hull #83

Engine power basis

per engine as printed on the page

Layouts & Drawings

1 drawing from the builder's page: general arrangement, sail plan, profile.

•

  34O-Layout-hi-res-scaled — Back Cove Yachts

About Back Cove Yachts

Premium production

Maine builder of Downeast-style motor yachts and Sabre's sister brand since 2003 — four models from the 12.1-metre 34O to the 14.1-metre 412, on a single inboard diesel or twin and triple Mercury outboards, built in Rockland.

Back Cove says it began with a group of Sabre dealers who pictured a smaller Downeast-style cruising boat, one that kept the charm and tradition of Maine's lobster boats but offered the simplicity, reliability and fuel efficiency of a single diesel engine. That boat became the Back Cove 29, and with it a new brand was born; it has been Sabre Yachts' sister brand since 2003. The company says that Sabre and Back Cove together are the largest recreational boatbuilder in Maine, the state where America's maritime story began with the first ships launched from the Kennebec River as early as 1607. Back Cove builds in a 240,000-square-foot plant in Rockland, Maine, using production-line methods and vacuum infusion, says it leads the 34- to 41-foot class, and counts more than 1,000 of its yachts cruising from Greece and Norway to Japan, Australia and New Zealand, as well as on almost every coast and inland lake in the United States. Its design rule is that every boat must 'be a boat first', balancing Maine heritage with innovation and refining layouts and systems from owners' feedback.

The Back Cove Yachts Range

Every model Back Cove Yachts publishes, by length — where this one sits in the range.

1. 41246.1 ft
2. 39O43.5 ft
3. 37242.7 ft
4. 34O· this model39.6 ft
